產品特點
1、將大顆粒破碎成小顆粒料的專用設備;
2、結構緊湊,三輥結構,使喂料更連續平穩,成品粒度均勻,破碎成品率提高。破碎均勻,粒度調節方便快捷;
3、軋輥實行差動轉速,顆粒料在兩軋輥間受到擠壓、剪切、撕裂作用,從而達到理想的破碎效果;
4、獨特的進料斗及旁路裝置既起到了勻料作用,又起到了對不需破碎的物料起旁流作用,旁流時通過行程開關實現自動停機;
5、采用窄V皮帶傳動,傳動平穩,噪音低,工作可靠,操作方便。
主要技術及性能參數
型號 參數 | SSLG20×80 | SSLG20×110 | SSLG20×140 | SSLG20×170 | SSLG25×170 |
產量 (t/h) | 5-8 | 5-10 | 8-12 | 12-20 | 15-20 |
配用動力 | 5.5+1.1 | 7.5+1.1 | 11+1.1 | 15+1.1 | 18.5+1.1 |
SSLG20 Series Triple-roller Crumbler
SSLG20系列三輥碎粒機
Features
1. It is the specific purpose equipment which crumbles big pellets into small ones;
2. Compact structure, evenly size, convenient and quick adjustment. The feeding roll is available to make the feeding smoother. The fineness of finished products is even and crumbled products obtaining rate is improved;
3. Rolls perform differential rotational speed. Pellets are pressed, sheared and torn, thus reaching ideal crumbling effect;
4. Unique feeding hopper and bypass device not only serve to distribute the products, but also serve to bypass the products not requiring crumbling. When bypassing, automatic stoppage is realized through limit switch;
5. V-shape belt driving is adopted. It is stable, low noise, reliable and easy to operate.
Main Technical Parameters
Model Parameters | SSLG20×80 | SSLG20×110 | SSLG20×140 | SSLG20×170 | SSLG25×170 |
Output (t/h) | 5-8 | 5-10 | 8-12 | 12-20 | 15-20 |
Power(kw) | 5.5+1.1 | 7.5+1.1 | 11+1.1 | 15+1.1 | 18.5+1.1 |
